Go like a Pro – with our MultiViu® displays, available now!
As a creative development team, you aspire to more than simply implementing those great ideas – you also want to deliver 100% professional results. Resources that can provide each component with the necessary individual attention and care are often lacking, particularly in the development of small series productions, special vehicles and even start-ups such as electromobility. Continental offers the perfect alternative for the display sector: MultiViu® displays. OEM quality, off-the-shelf.
Zero development costs,
100% Continental technology.
MultiViu® stands for directly available displays that incorporate all the know-how and experience of one of the world’s leading automotive suppliers, especially in display technology: Continental. You save all the development work and still have a display in OEM quality. MultiViu® makes life easy!
Economical, professional and flexible: Perfect for those great ideas.
No idea is too big for MultiViu®, because these displays fulfill almost every imaginable wish.
The MultiViu® Compact 7 even lets you select the orientation in landscape or portrait format. The multi-talented Compact 7 also gives you optional touch functionality for maximum intuitive operating concepts.
All MultiViu® displays can be individually configured with our powerful Toolchain, and the graphic design of the interface can be perfectly adapted to your requirements.
Call a halt to those long development processes – just grab it and go. That’s MultiViu®. More than worthwhile, even for small quantities!
Ready for use in all conditions:
MultiViu® Compact 7
The excellent performance and display quality of the MultiViu® displays totally convince every user. For particularly tough usage scenarios such as in agricultural vehicles and construction machinery, we recommend our MultiViu® Compact 7 with outstanding performance features:
- Optical bonding technology for easy readability even under difficult lighting conditions
- Integrated brightness sensor
- IP65 protection class enables use in tough environments
-
MultiViu® Compact4
MultiViu® Compact4
Platform, off-the-shelf 4.3 inch Display Solution
- A platform, off-the-shelf display unit solution, based on TFT display controllers
- Modular architecture for easy customization (button backlight, Logo, telltales, color-stripes)
- 10 dual backlight telltales
- Application programming by logi.CAD and grADI (Kibes)
- Affordable, low customization cost
- Black-panel effect
Technical Specifications
- 4.3 inch 16: 9
- 480 x 272 pixel
- 800cd/m² min
- contrast 700:1 min.
- Transmissive display
- 2 CANs, GPIO’s available
- Compatible with PAL and NTSC cameras
- Operating voltage 12/24V
- Protection class IP 67
-
MultiViu® Compact7
MultiViu® Compact7
Platform, off-the-shelf 7 inch Display Solution
- A platform, off-the-shelf display unit solution, based on TFT display controllers
- Modular architecture for easy customization (Logo, telltales, color-stripes)
- 24 backlight telltales
- Easy model based application programming with logi.CAD and grADI (Kibes)
Technical Specifications
- 7.0 inch 15:9
- 800x480 pixel
- 800cd/m² min.
- Contrast 1000:1 typ.
- Transmissive display
- Capacitive touch function and mineral glass + optical bonding
- 2 CANs, GPIO’s available
- Compatible with PAL and NTSC cameras
- Operating voltage 12/24V
- Protection Class IP 65 front
-
MultiViu® Professional12
MultiViu® Professional12
MultiViu® Professional 12 – an instrument cluster with a 12.3-inch color display and maximum design freedom, where even animations and videos can be implemented. The MultiViu® Professional 12 is fully programmable and adapts to your individual requirements. Through its modular structure, it fits seamlessly into any front frame.
Technical Specifications
- Super wide-view 12,3 inch color TFT-display with resolution of 1440 x 540 px in 8:3 format
- Programing and control of graphics, texts and animations via CGI Studio
- Functional programming and control of instrument and Human Machine Interface via KIBES® 5
- Software based on OSEK and Linux operating systems
- Several interfaces available: high-speed CAN, video, LIN, I/Os, Audio, Ethernet
Features & Benefits
- Flexible, adaptable and situational controlled Human Machine Interface according to “Simplify your drive”
- Performance software to fulfill graphics and pointer animation requirements
- Trend towards larger and colored displays, to manage and indicate increasing amount of driver information and driver assistance functionality
- Very powerful hardware to support flexibly the increasing needs of future Human Machine Interface needs
- Guarantee of time- and cost-optimized development during project phase and vehicle’s lifetime by use of Continental's software toolchain
